Instruction Manual

Drive Status Indicators

LED Status Description

An error has been detected on one or more

hard drive.

OFF

RAID array is currently rebuilding.

OFF

eSATA/USB/FireWire Connectivity

The LED indicators will show which host interface is currently active on the enclosure.

To switch interfaces, shut the enclosure o and disconnect old cable and then connect

the new cable and turn the enclosure back on. Only one interface can be active at a

time, so it is recommended that only one cable be connected at a time to ensure the

proper interface is chosen.

LED Status Description

eSATA connection active

OFF

USB connection active

OFF

FireWire interface active

OFF
